Why every bridge is made of triangles: a square frame folds, a triangle can't

A green triangulated bridge truss on a black background, with the title 'Why every bridge is made of triangles'
30seconds
The 30-second version

Push on the corner of a square frame and it folds flat. Push on a triangle made of the same sticks and nothing moves. The reason is simple: three side lengths fix a triangle's shape, but four don't fix a square's.

Drag the joints of a pin-jointed frame, add or remove bars, and watch a live count of how many ways it can still fold. You'll see why bridges, cranes and roof frames are nets of triangles.
